Beacon Light Pro V2 Identification Beacon

The Zephyr Beacon Light Pro V2 remote identification beacon allows any aircraft to comply with regulations.

It is intended for drones not equipped by default with the device and which have a 5V to 8.4V output to power the beacon, and which require an extended range of 3 km.

It has a web interface that allows you to check the operation of the beacon and display other nearby beacons in reception mode.

The Light Pro beacon is designed to be integrated inside the drone and must be powered by a 5V to 8.4V voltage source. An LED indicates its status. Its featherlight weight of only 23 g allows the device to be integrated into very small aircraft. Its low power consumption of 40 mA on average does not penalize the drone's autonomy. The external antenna provides a range of 3 km in optimal conditions and facilitates integrations where the antenna needs to be relocated outside the drone's chassis. It has a web interface that allows you to check the operation of the beacon and display other nearby beacons in reception mode.

Technical specifications

2.4 GHz frequency (2437 MHz)

WIFI Channel 6

External antenna

Range 3 km

Total weight 23 g

Dimensions 35 x 21 x 13 mm + antenna

Supply voltage 5 to 8.4V
